TECO ie3 cast iron squirrel cage induction motors are designed, manufactured and tested in accordance with the latest European and international standards. Reliable and high-quality structure is the ideal choice for all industrial markets
The output power ranges from 0,75kw to 400KW, and the overall dimensions range from 80 to 355. This motor adopts NEMA mg-1 design and conforms to NEMA premium standard. Its output power ranges from 1 HP to 420 HP *, and its overall dimensions (metric system) range from 80 to 315
*For NEMA premium efficiency output (horsepower), please consult us: marketing@motovario.it
Product characteristics
Design standard IEC60034
Energy efficiency grade ie3, in line with iec/en 60034-30-1 standard
NEMA premium energy efficiency, NEMA mg-1 compliant
230V to 690V, 50/60 Hz
Overall dimensions 80 to 355
Detachable footing design 80 to 280
IP55 standard
Double sided double lip seal
Winding insulation f/b
3 off PTC with clamp connection
C3 coating with ral7032 color number
Prepare inverter according to iec60034-17
SKF, NSK or fag bearing
IC411
Grade 8.8 bolt
